Semi-Automatic Block Making Machine QTJ4-40

Description

QTJ4-40 semi-automatic concrete hollow block making machine meets the state standards of GBT8533-1998, which is excellent in performance, high in efficiency, and low in energy consumption.
The block making machine, through mould and by application of fly ash and other industrial waste, can produce all kinds of hollow block, solid block, which are widely used in the construction of municipal works, buildings, and garden sand roads. What’s more, the machine has a high productivity.

Features

QTJ4-40C block making machine adopts the mechanical transmission. The products look beautiful, clear edges and corners, and the error rate is more or less than 3%.
QTJ4-40 semi-automatic concrete hollow block making machine can produce various types of load-bearing and non-load-bearing blocks by using the coal gangue, coal ash, slag, ceramic clay, gypsum and other industrial waste.
Topmac is an ISO 9001 accredited block making machine supplier in China.

Main Technical Specification

Power	9.6kw
Overall Size	1580×1100×2100mm
Cycle	40S
Carriage Size	850×550 X 30mm
Vibration Frequency	max.3000r/m
Electrical source	380V/50Hz
Total Mass	1500kg

Capacity Table

Block size	pcs/mould	pcs/hour	pcs/8 hour
400x200x200mm	4	320	2560
400x150x200mm	5	400	3200
400x100x200mm	6	480	3840
